8-inch 3-way full-range speaker
The private custom CI-181 is made up of a 1-inch horn treble, a Private custom CI-181, three-frequency design, can be used as the main speaker box or
large space around. the tone is rich and sweet, high frequency transmission can be externally
controlled and regulated, the sound pressure is dynamic and the frequency range is wide.
the tone color can be modified according to the space application and environment with high
tun ability. It's got a body, it's got a body frequency division, into the wall installation.
System parameters:
Speaker Type: Embedded、Hidden
Treble converter: 1 inch horn treble
Treble converter: 28-core wire super high tone
Low-frequency inverter: 8-inch carbon fiber composite bass
Rated power: 120W
Frequency response: 60Hz-20KHz
Rated impedance: 4 ohms
Sensitivity: 85dB
Connector Type: red and black terminal
Available surface: Black brushed aluminum panel
Pure aluminum brushed panel size: 315 wide × 470 high × 10 deep mm
Installation opening size (box size): 295 wide ×445 high × 120 deep mm
系统参数:
扬声器类型: 嵌入式、隐藏式
高音变频器: 1寸号角高音
